PDB Series High Efficiency Programmable DC Power Supply

The PDB Series is a high-precision, high-stability water-cooling DC power supply with a maximum output power of 40kW with a standard chassis design. This series are widely used in lasers, magnet accelerators, semiconductor preparation, laboratories and other demanding industries.

ASK

Data Table

Features

● Standard 3U chassis design
● Chinese human-computer interaction interface
● Wide volage design to meet various power grid uses
● IGBT inverter technology and high-speed DSP as the control core
● Automatic switching between constant voltage and current
● Telemetry function to compensate voltage drops on load lines
● High-precision regulation of voltage and current through a digital encoder
● Support over 10 conventional industrial bus communications
● External analog programming and monitoring (0-5V or 0-10V)
● Support multi-machine parallel operation
● Light weight, small size, high power factor and high efficiency
● CE certification qualified

The main parameters

Input	Parameter
Input
Input Voltage	AC220V, AC380V
Input Frequency	50/60 Hz
Control Power Supply	AC110–AC240V
Output
Output Current	5, 10, 20, 30, 40, 50, 60 A
Performance Index
Stability	≤0.2%
Control Accuracy	≤0.2%
Performance Index
Operating Mode	Phase-shift trigger, power regulation fixed period, power regulation variable period
Control Mode	α, U, I, U², I², P
Load Property	Resistive load, inductive load
Setting Mode	Analog input: DC4mA–20mA, DC0V–5V, DC0V–10V; communication setting or keyboard setting
Analog Output	DC0–10V
Switching Input	2-way, normally open
